How To Reset An RCD
Find The RCD
The RCD will usually be in an RCD ‘domestic unit’. The RCD domestic unit will contain about 10 RCDs.
The RCD domestic unit will usually be in an ‘out of the way’ place, for instance next to the electricity meter, at the back of a kitchen unit, in an airing cupboard, the cupboard under the stairs.
The RCD will be about 2 inches (5cm) by 1 inch (2.5cm) and will have a ‘standard’ toggle switch (the ‘main’ switch) and a push-button ‘push-button’ (test) switch. The RCD domestic unit will have thick (large diameter) cable going into it – this cable is the ‘main ring’ cable.
To reset an RCD move the main toggle switch to the other position; if down move up, if up move it to the down position.
How To Investigate A Constantly Tripping (Resetting) RCD
Look at the RCDs.
Is one main toggle switch in a different position to the rest? Is one main toggle switch up and the other RCD main toggle switches down or down when the rest are up?
If one RCD main toggle switch is in a different position to the rest move it to the same position.
Moving the main toggle switch is called ‘resetting the RCD’.
If the RCD stays reset, the main toggle switch does not go back to the other position, the problem is solved.
If the RCD does go back to the other position this is called ‘a constantly tripping’ RCD – see below.
Homeowners should be aware that some RCD domestic units have their own ‘trip switches’, some domestic units have their own isolation switches (on\off switches).
These switches may be standard ‘toggle’ type or ‘push button’ type. Are the domestic unit switches in the correct position?
An RCD that trips again (and again) after reset is a ‘constantly tripping RCD’. The problem is unlikely to be the RCD. The problem is most likely an electrical appliance causing the RCD to trip; the RCD is ‘doing its job’; the RCD is removing the supply to an unsafe electrical circuit.
What Causes An RCD To Trip
The approach is to remove (disconnect) as many electrical appliances from the circuit as possible and then connect them back into the circuit one at a time. The faulty appliance will cause the RCD to trip; the shows the homeowner which appliance is faulty (causing the RCD to trip).
The homeowner should remove (unplug) all electrical appliances. If it is not possible to unplug an appliance, turn the appliance off.
After unplugging all appliances, or turning them off, see if the RCD will reset. If the RCD will reset, the fault is with one of the appliances; if the RCD trips again the fault is with the electrical circuit – call a qualified electrician.
Plug each appliance in one at a time. After plugging the appliance in, or turning an appliance on, reset the RCD; keep plugging the appliances in, and resetting the RCD, until the RCD trips.
Connecting the appliances one at a time, and resetting the RCD in-between, shows the homeowner which appliance is causing the RCD to trip. The homeowner should repair, or replace, the faulty appliance.
Plugging each appliance in one at a time is not a100% guarantee of finding the faulty appliance; it is the best way, but not a 100% guarantee. Certain ‘cause\effect’ situations can suggest a, say, faulty kettle when the real problem is, say, a faulty cooker.
